Product Details:
Payment & Shipping Terms:
|
| Prodcut Name: | Hand Held Rotary Vane Vacuum Pump | Usage: | Air Pump |
|---|---|---|---|
| Power: | Electric, 1/5Hp | Electric: | 220V/50Hz 110V/60Hz |
| Ultimate Vacuum: | 3.5-10pa | Flow Rate: | 2.5-10CFM |
| Number Of Stage: | 1 | Use For: | Refrigareation Maintance,Packing,Medical,Printing Etc. |
| High Light: | Handheld Rotary Vane Vacuum Pump,10pa Rotary Vane Vacuum Pump,Medical Rotary Vane Vacuum Pump |
||
Hand Held Rotary Vane Vacuum Pump
Features of Rotary Vacuum Pump
Light weight, compact design, low noise
Gas ballast design, for better compatibility with moisture and solvent vapor
Check valve to prevent pump oil backflow
Different options for gas-taking speed (1L/s, 2L/s & 4L/s)
Different options for vacuum connectors (KF25, hose barb, etc)
Available in both 220V and 110V version
Technical Data
| Item No. | 2VP215 | 2VP225 | 2VP245 | 2VP260 | 2VP2100 | VP125 | VP145 | VP1100 | |
| Flow rate | 50Hz/220V | 1.5CFM | 3.5CFM | 4.5CFM | 8CFM | 10CFM | 2.5CFM | 4.5CFM | 10CFM |
| 42L/min | 70L/min | 100L/min | 170L/min | 226 L/min | 70 L/min | 128 L/min | 283 L/min | ||
| 60Hz/110V | 1.8CFM | 3CFM | 5CFM | 7CFM | 12CFM | 3CFM | 5CFM | 12CFM | |
| 50L/min | 84L/min | 114L/min | 198L/min | 254L/min | 84L/min | 142L/min | 340L/min | ||
| Ultimate vacuum | 3.5Pa/25microns | 10Pa/75microns | |||||||
| Number of stages | 2stage | 1stage | |||||||
